Innovative Technologies for Botanical Oil Extraction

glass container

Pure Performance

Evello® International believes in leading the botanical oil extraction industry in a more innovative direction – with an approach that combines innovative technologies with personalized consulting services focused on helping our clients establish successful businesses.

As such, we’ve designed our product offering to deliver extraction with exceptional purity, maximized output, and reliable, repeatable results. Evello’s® proprietary technology is patented and designed to deliver high quality botanical extracts. Our closed-loop systems are designed to complete multiple functions in a single, streamlined process, allowing for scalability, and maximized profitability without unnecessary complication or ancillary equipment.

All Evello® products provide clean, efficient extraction through:

Medical-grade stainless steel construction

GMP-compliant design

Durable, long
serviceable life

Operator-friendly interface

Programmable semi-automated systems

Included solvent recovery

Option to purchase or license depending on volume and output

Installation included for all product purchases

Additionally, all individual components of Evello® Equipment are either UL or CE Certified for safety, and equipment can be configured in compliance with Organic or Kosher (U, K) standards.

Evello® Product Listing

Evello® 250 L

An ideal purchase for smaller-scale or start-up extraction businesses, or for product line extensions within a larger catalog or offering. Processes up to 110 lbs. per batch and equipped to process multiple batch cycles per day.

Length – 40 feet

Width/Depth – 8 feet

Height – 10 feet

Approximate Footprint – 350 Sf

Throughput – up to 110 pounds per batch

Interior Finish – Stainless steel 304 (medical grade)

Capacity – 250 Liters

Run Time (approx) – 4 hours

Warranty – 1 year

Includes:

  • 1x Ultrasonic cellular disruption device
  • Condensers, Cooler, and Oil/Water Separator
  • Control Cabinet
  • 1x VFDs for variable speed control of the agitators inside the extractor
  • Filtration
  • 1x Ertelalsop Chlorophyll and Particulates Filtration System 316SS
  • Sedimentation (winterization) Tank 304SS
  • Wiped Film Evaporator Unit  304SS
  • Molecular Distillation Unit 304SS

Evello® 1000 L

Created for larger operations seeking to increase daily production without adding the larger footprint necessary for multiple smaller systems to run simultaneously, this unit processes batches up to 733 lbs., and is available for purchase or licensing.

Length – 115 feet

Width/Depth – 20 feet

Height – 15 feet

Approximate Footprint – 2,300 Sf

Throughput – up to 733 lbs per batch

Interior Finish – Stainless steel 305 (medical grade)

Capacity – 1,000 Liters

Run Time (approx) – 4 hours

Warranty – 1 year

Includes:

  • 1x Ultrasonic cellular disruption device
  • Condensers, Cooler, and Oil/Water Separator
  • Control Cabinet
  • 1x VFDs for variable speed control of the agitators inside the extractor
  • Filtration
  • 1x Ertelalsop Chlorophyll and Particulates Filtration System 316SS
  • Sedimentation (winterization) Tank 304SS
  • Wiped Film Evaporator Unit  304SS
  • Molecular Distillation Unit 304SS

Evello® 3000 L

Available under licensing agreement only, the Evello® 3000 L provides maximum throughput and all-in-one processing in a single system, along with additional service, support, updates, and more.

Length – 187 feet

Width/Depth – 34 feet

Height – 19 feet

Approximate Footprint – 6,348 Sf

Throughput – up to 2,200 lbs per batch

Interior Finish – Stainless steel 305 (medical grade)

Capacity – 3,000 Liters

Run Time (approx) – 4 hours

Warranty – 1 year

Includes:

  • 1x Ultrasonic cellular disruption device
  • Condensers, Cooler, and Oil/Water Separator
  • Control Cabinet
  • 1x VFDs for variable speed control of the agitators inside the extractor
  • Filtration
  • 1x Ertelalsop Chlorophyll and Particulates Filtration System 316SS
  • Sedimentation (winterization) Tank 304SS
  • Wiped Film Evaporator Unit  304SS
  • Molecular Distillation Unit 304SS

*Equipment and process specifications are subject to change as process improvements are made.
